Sectron EGS5 GPRS JAVA Terminal - Terminal Specifications: PHS8 Series

8
PHS8 HSPA+ Terminal, PHS8-P HSPA+ Terminal Audio
RS232 – Connector for terminal connection via RS232
+ - – Power connection terminals 8 – 30 V DC (polarity must correspond to the engraving)
GSM – LED is inactive after the device is switched on; function can be set by command
AT^SLED (option cannot be saved)
SIM – SIM card slot
PWR – LED diode that indicates the power status, it lights up green when the device is turned on
USB – USB connector for connection to computer
GSM – Main Antenna for GSM signal reception
GPS – Antenna for GPS reception
DIV – Diversity antenna to improve GSM signal REP – Speaker output
MIC – Microphone input
Name
PHS8 HSPA+ Terminal
PHS8-P HSPA+ Terminal Audio
GSM module
Gemalto M2M GmbH -
Cinterion PHS8-E
Gemalto M2M GmbH - Cinterion
PHS8-P
Frequency bands GSM
900/1800/2100 MHz
800/850/900/1800/1900/2100 MHz
Communication speed(Mbps)
14,4/5,76
14,4/5,76
User interface
RS-232, USB
RS-232, USB
Operating temperature range
-20
0
C up to +55
0
C
-20
0
C up to +55
0
C
Operating temperature range
-40
0
C up to +85
0
C
-40
0
C up to +85
0
C
Power voltage
8 – 30 V DC
8 – 30 V DC
Power consumption
1 W / 3.5 W (receive /
transmit)
1 W / 3.5 W (receive / transmit)
Antenna connector
SMA(f) 50 Ohm
SMA(f) 50 Ohm
Dimensions
25 x 54 x 97 mm
25 x 54 x 97 mm
Mounting
DIN rail 35 mm
DIN rail 35 mm
Weight
110 g
118 g
