Sectron EGS5 GPRS JAVA Terminal - Terminal Specifications: ELS61 LTE

10
M
ELS61 LTE JAVA Terminal USB
RS232 – Connector for terminal connection via RS232
PWR ~ – Power connection terminals8 – 30 V AC/DC (polarity does not matter)
LED power diode – LED diode that indicates the power status, it lights up green when the device is
turned on
ANT – Antenna for GSM signal reception
SIM – SIM card slot
DIV – Diversity antenna to improve GSM signal
LED diode SIM – 1:1 – terminal not logged into GSM network
– 1:9 – terminal is registered into GSM network
USB – USB connector for computer connection
– In the case of the terminal with „USB“ in the name, the terminal can also be powered via
the USB port
Name
ELS61 LTE Terminal USB
GSM module
Gemalto 2M GmbH - Cinterion ELS61
Frequency bands GSM
850/900/1800/1900/2100/2600 MHz
Communication speed(kbps)
100/50
User interface
RS-232 / USB
Operating temperature range
-20
0
C up to +55
0
C
Operating temperature range
-40
0
C up to +85
0
C
Power voltage
8 – 30 V DC
Power consumption
1 W / 3.5 W (receive / transmit)
Antenna connector
SMA(f) 50 Ohm
Dimensions
25 x 54 x 97 mm
Mounting
DIN rail 35 mm
Weight
102 g
