PUBLIC BGX501-747-R04, Premier 300 User Manual Page 11 of 41
7 General Specifications
The general specifications for Premier 300 are summarised below:
Table 3: General Specifications for Premier 300.
Specification Description
Mechanical
Dimensions (mm) 191 (L) x 256 (W) x 82 (H) mm approx
Weight 1.6 kg approximately
Mounting Type Projection type
Front Cover Fire-retardant polycarbonate (PC-FR)
Base PC-FR material
Extended Terminal Block
Cover
PC-FR material
Terminal Block 10% Glass filled PC-FR material
Sealing Provision
2 seals on ETBC, 1 seal on IEC 1107 port, 1 seal on the left button
and 3 seals on the front cover
Display Super Twisted Nematic (STN) LCD with backlit
Electrical
Meter Type 3 Phase, 4 Wire (LT and HT) and 3 Phase, 3 Wire (HT)
Measuring Elements 3 CT for LT, 3 CT for HT4 and 2 CT for HT3
Rated Voltage 3*230/240V or 63.5 V(P-N) for HT4 and 110V(P-P) for HT3
Frequency 50 Hz ± 5%
Current Rating 5-10A for LT, 1(2)A or 5(10)A for HT
Power Factor Zero Lag <–> Unity <->Zero Lead
Accuracy HT: 0.5S, 0.2S or LT: 0.5S
Metrology lamp Metrological LED
Compliance
Metrological
DLMS Indian Companion Standard (IS15959), IS
14697, CBIP Report 304, IEC 62053-22
Environmental Protection IP51
Burden
Voltage Circuit (per
phase)
<1W,<6VA
Current Circuit (per
phase)
<1VA
