SL150 Installation and Setup Guide
26–2
SL6150 REMOTE KEYPAD
Error!
Bookmark not defined.
1. Physical: 6-1/2” W x 5-7/8” H x 1-5/16” D (150mm x 124mm x 33mm)
2. Electrical:
Voltage Input: 12VDC; Current Drain: 40 mA Standby;
70mA with ARMED LED lit, LCD backlit and sounder on.
3. Interface Wiring:
To control panel's terminal strip connection points:
Keypad Connector
.....
DO
:
Keypad Connector
.......
+:
Keypad Connector
.......
–:
Keypad Connector
......
DI
:
Terminal 7: Data Output from control to keypad.
Terminal 5: +12VDC
Terminal 4: –12VDC Rtn (Ground)
Terminal 6: Data Input from keypad to control.
SL6150RF REMOTE KEYPAD
1. Physical: 6-1/2” W x 5-7/8” H x 1-5/16” D (150mm x 124mm x 33mm)
2. Electrical:
Voltage Input: 12VDC; Current Drain: 50 mA Standby;
100mA with ARMED LED lit, LCD backlit and sounder on.
3. Interface Wiring:
Same as SL6150 Keypad
SL6160 REMOTE KEYPAD
1. Physical:
7-1/4” W x 5-1/4” H x 1-1/2” D (184mm x 133mm x 38mm)
2. Electrical:
Voltage Input: 12VDC; Current Drain: 40 mA Standby;
150mA with ARMED LED lit, LCD backlit and sounder on.
3. Interface Wiring:
Same as SL6150 keypad.
5881/5882 SERIES RF RECEIVERS (5800 System)
1. Physical:
7-3/8” W x 4-3/8” H x 1-7/16” D (188mm x 112mm x 37mm)
Note:
10-7/8” (277mm) high with antenna
2. Electrical:
Voltage Input: 12VDC; Current Drain: 35mA
3. Interface Wiring:
To control panel's keypad connection points.
4. Range:
200 ft (60m)
nominal
indoors from wireless transmitters
(the actual range determined with system in Test mode).
5. Zones:
(
With the
Ademco SL150
)
5881L/5882L: accepts up to 8 transmitters
5881M/5882M: accepts up to 16 transmitters
5881H/5882H: accepts up to 30 transmitters
5800TM TRANSMITTER MODULE (used with 5827BD Wireless 2-Way Keypad)
1. Physical:
2-1/4” W x 4-1/8” H x 7/8” D (57mm x 105mm x 22mm)
2. Electrical:
Voltage Input: 12VDC; Current Drain: 20mA
3. Interface Wiring:
To control panel's keypad connection points
4219 WIRED EXPANSION MODULE
1. Physical:
6-1/2” W x 4-1/4” H x 1-1/4” D (169mm x 108mm x 32mm)
2. Electrical:
Voltage Input: 12VDC; Current Drain: 35mA
3. Interface Wiring:
To control panel's keypad connection points
4. 8 EOLR Loops (A–H):
Loop A can be set for fast (10–15mSec) response to an open.
