Security Link SL150 - Section 1 Introduction; General Description; Features

1–1
SECTION 1
Introduction
••••••••••••••••••••••••••••••••••••••••••••••••••
In This Section
♦
General Description
♦
Features
••••••••••••••••••••••••••••••••••••••••••••••••••
General Description
The SL150 is a security system control that supports up to 38 zones, including eight basic
hardwired zones (1 through 8) and a maximum of 30 expansion zones. These expansion zones
may include up to eight hardwired zones, or up to 30 wireless zones if hardwired zones are
not used. Three separate keypad-activated zones are also provided.
Features
Basic Hardwired Zones
Provides 8 basic hardwired zones having the following characteristics:
• EOLR supervision supporting N.O. or N.C. sensors
• Programmable response time (10, 350, or 700 milliseconds)
• Up to sixteen 2-wire smoke detectors on zone 1
• 4-wire smoke or heat detectors on zones 2 through 7 (as many as can be powered
from AUX power on the control)
• Up to fifty 2-wire latching type glassbreak detectors on zone 8 with auto reset
Optional Expansion Zones (up to 30 total, wired and wireless)
Wired Expansion:
Supports up to 8 additional wired zones using a 4219 expansion module or 4229
expansion/relay module. These zones have the following characteristics:
• EOLR supervision supporting N.O. or N.C. sensors
• 300–500 msec normal response with an option for fast (10–15 msec) response on
loop A (first expansion zone)
Wireless Expansion:
Supports up to 30 wireless zones (less if using wired expansion zones).
• Requires the use of a 5881(5882 in Canada) type RF Receiver
*
, as follows:
Model 5881L/5882L Up to 8 zones
Model 5881M/5882M Up to 16 zones
Model 5881H/5882H Up to 30 zones
*
Requires the use of 5800 series wireless transmitters
Remote Keypads
Up to 8 of any of the following keypads may be used in the installation:
Fixed-Word Keypads: SL6150 (Part No. 6150PL3), SL6150RF (Part No. 6150RFPL3)
Alpha Keypad: SL6160 (Part No. 6160PL3)
For programming from a keypad, an SL6160 2-line Alpha keypad must be connected, but need not
remain in the system after programming has been completed.
