Section 4 – Basic Hardwired Zones
4–7
Programming For The Remote Keyswitch
1. Using a 2-line Alpha keypad, enter the programming mode by entering:
Installer code + 8 + 0 + 0 keys.
If RF zones, wired expansion, or a keyswitch will be used, data fields
✱
22 RF SYSTEM,
✱
25
WIRED ZONE EXPANSION and
✱
30 KEYSWITCH ENABLE must be programmed as required
prior to continuing.
Note: If keyswitch is enabled, in menu mode
✱
56 the Zone Type (ZT) for zone 7 will show
“77”, and will not be accessible for programming.
2. Press
✱
56.
Note that this is an interactive programming mode. You will use it to program zone 7 for
alarm report codes and to program response time (zone type will automatically show as
“77”).
Enter Zn Num.
(00 = Quit) 01
Zone Number
↑
Upon entering
✱
56
mode, this prompt will be displayed.
Enter zone number “07”.
Following this entry, press [
✱
] to continue.
Typical summary display
Zn ZT RC In RT
07 77 00 HW: 1
A summary display will appear, showing the present
status of zone 7's programming.
Zn = zone number;
ZT = zone type;
RC = report code for that zone;
In = input type of zone;
RT = response time for that zone.
Values displayed are the factory defaults for zone 7 or, if
this is not a new installation, they are the currently
programmed values.
↓
Zone Number
07 Zone Type
77
Zone Type
↑
To program zone 07, press
[
✱
].
Zone type will be automatically displayed as “77”, and
no entry is required.
Press
[
✱
]
to continue.
07 Report Code
1st 03 2nd 12 3C
The report code consists of 2 hexadecimal digits, each in
turn consisting of 2 numerical digits. For example, for a
report code of "3C", enter [0][3] for "3" and [1][2] for "C".
If necessary, refer to the SYSTEM COMMUNICATION
section for complete information on report codes.
Enter the desired numbers and then press [
✱
] to
continue.
07 Response Time
1
If keyswitch is enabled (in programming mode, field
✱
30
)
, the response is preset to 350ms. Therefore no
entry is required.
Press [
✱
] to continue.
