Section 15 -Data Field Descriptions
15–7
TO PROGRAM
SYSTEM STATUS
AND RESTORE
REPORT CODES
✱
✱
✱
Report codes can be programmed using the interactive
✱
Mode or
✱
58 Expert Mode, or codes can be entered in data fields
✱
59 -
✱
76,
✱
89.
The following is a set of guidelines to be used for programming report codes. The
actual report code digits that you enter depend upon the particular installation, and
should be in agreement with you and the central station office receiving the signals.
Use these guidelines to program this entire section.
With a 3+1 or 4+1 Standard Format:
Enter a code in the first box: 1–9, A, B, C, D, E,
or F. Enter "#+10" for A (this reports a “0” on some receivers), "#+11" for B, "#+12" for
C, "#+13" for D, "#+14" for E, "#+15" for F.
An entry of "0" in the
first
box will disable a report.
An entry of "0" in the second box will result in automatic advance to the next field when
programming.
With an Expanded or 4+2 Format:
both
boxes (1st and 2nd digits) for
1–9, or A–F, as described above.
An entry of "0" in the first box will disable a report.
An entry of "0" in the second box will eliminate the expanded message for that report.
With Ademco Contact ID Reporting:
Enter a digit in the first box to enable the zone
to report. Use a different digit for each zone until you have used up available digits. If
the number of zones exceeds the number of available digits, begin with digit 1 again.
This is an "enabling" code only and is not the actual code sent to the central station
office. Entries in the second boxes will be ignored. For system status (non-alarm) codes,
enter a “1” in the first box for all the system conditions you want to send to the central
station.
An entry of "0" in the first box will disable the report
.
SYSTEM STATUS
REPORT CODES
✱
✱
✱
59 EXIT ERROR REPORT CODE
(See box above)
0
If the system is armed and an entry/exit or Interior zone is still open after the
Exit Delay time has expired, an alarm will sound at the keypad and external
sounder (keypad also displays EXIT ALARM). If the system is disarmed
before the end of the Entry Delay that immediately follows, the alarm
sounding will stop
and no message will be sent to the Central Station
.
The keypad will display
CA
(on fixed-word keypads) or
CANCELED
ALARM
(on alpha keypads).
If the system is
not
disarmed before the end of the entry delay mentioned
above, and an entry/exit or interior zone is still open, an “Exit Alarm”
message will be sent to the Central Station if an Exit Error
Report
code
is selected in this field.
The keypad will display
EA
(on fixed-word
keypads) or
EXIT ALARM
(on alpha keypads), and the alarm sounding will
continue until the system is disarmed (or timeout occurs).
An Exit alarm condition will also result if a fault occurs in an exit or interior
zone within 2 minutes following the end of the exit delay, and an “Exit Alarm”
message will be sent to the Central Station.
If Contact ID format has been programmed,
the message will contain the zone
number and error code 374 (“Trouble–Exit Error”) to define the alarm as an
Exit Error (rather than E/E or Interior). This message will go to the primary
phone number. Under any of these conditions, no “Restore” message will be
sent.
If 0 is entered in this field, no special message will be sent, only the regular
Alarm and Alarm Restore code for the zone.
