Sedgwick TA315 - Technical Specification and Shipping

TA Operation/Maintenance Instructions Page 6 of 36
1.2 Technical Specification
TA315
SAW BLADE DIAMETER
315mm
SAW BLADE BORE
30mm
SAW BLADE PROJECTION @ 90
0
@ 45
0
105mm
76mm
SPINDLE SPEED
3700rpm
MOTOR RATING 3ph
1ph
3.0Kw IE2 (S1)
3.0Kw (S1)
SIZE OF TABLE LENGTH
WIDTH
800mm
750mm
HEIGHT OF TABLE
850mm
DISTANCE SAW TO FENCE
610mm
FENCE WITH MICRO ADJUSTMENT
600x75mm
DUST EXTRACTION OUTLET MACHINE
SAWGUARD
150mm
50mm
TOTAL AIR VOLUME REQUIRED
1445CMH
620mm CROSS CUT TABLE
OPTIONAL
TABLE SIZE LENGTH
WIDTH
600mm
350mm
DISTANCE SAW TO MITRE FENCE
620mm
1220mm PANEL SIZING TABLE
OPTIONAL
TABLE SIZE LENGTH
WIDTH
950mm
1000mm
DISTANCE SAW TO MITRE FENCE
1220mm
RIGHT HAND EXTENSION TABLE
OPTIONAL
TABLE SIZE LENGTH
WIDTH
800mm
700mm
DISTANCE SAW TO MITRE FENCE
1220mm
REAR TAKE OFF TABLE
OPTIONAL
TABLE SIZE LENGTH
WIDTH
800mm
700mm
1.3 Shipping Details
TA315
DIMS (machine only) L x W x H
GROSS WEIGHT
1500x1200x1200mm
345 kg
DIMS (c/w 1220mm Panel Table)
DIMENSIONS (Support Bar)
GROSS WEIGHT
1500x1200x1300mm
2720x250x200mm
466 kg
