9-2 SYSTEM TEST MODE
● Any settings that are changed by users during TEST MODE are saved upon exiting
TEST MODE with the EXIT command in the SYSTEM MENU. If the unit is
powered off prior to exiting, changes to settings will not take effect.
● You may not enter GAME TEST MODE while the unit is reading from or checking
the GD-ROM. If error messages are displayed when exiting
TEST MODE, you
should power the unit off and on again.
● In the manual for this product, "Media Board" and "DIMM" are one and the same.
● Use with the specified settings. If settings other than those specified are used,
inappropriate operations or malfunction may occur
.
A. SYSTEM TEST MENU MODE
● Press the TEST Button after powering on the unit to display the following SYSTEM MENU.
● Press the SERVICE Button to move the cursor to the desired test item.
● Move the cursor to the desired item and press the TEST Button to display each test screen.
● Move the cursor to ENTER GAME TEST and press the TEST Button to enter the individual test menus
for each game. Refer to "9-3 GAME TEST MODE".
● When testing is complete, move the cursor to EXIT and press the TEST Button. The game advertisement
screen should be displayed.
System
Test Mode can be used to check that the main circuit operations are correct, adjust Monitor color,
and perform coin/credit settings.
However
, this product can only be used with the settings shown below.
● SOUND TEST
- OUTPUT TYPE: STEREO
● COIN ASSIGNMENTS
- COIN CHUTE TYPE: COMMON
- SERVICE TYPE: COMMON
SYSTEM MENU
MEDIA BOARD TEST
SYSTEM INFORMATION
JVS TEST
SOUND TEST
C.R.T. TEST
COIN ASSIGNMENTS
CLOCK SETTING
NETWORK SETTING(CORE)
NETWORK SETTING(MEDIA)
ENTER GAME TEST
[*******************]
→EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
STOP
IMPORTANT!
