F. C.R.T. TEST
Use the C.R.T. TEST to adjust monitor colours and verify screen size.
COLOR CHECK Screen
● Monitor COLOR CHECK screen is displayed initially.
Each of the colors (red, green and blue) is darkest at the far left and gets progressively lighter (32 steps)
towards the right.
Monitor brightness is set correctly if the white color bar is black at the left edge and white at the right
edge.
● Press the TEST Button to proceed to the next page.
SIZE CHECK Screen
● Adjust the CHECK GRID so that the entire GRID is displayed on the screen.
● Press the TEST Button to return to the SYSTEM MENU screen.
C.R.T. TEST 1/2
1 32
RED
GREEN
BLUE
WHITE
PRESS TEST BUTTON TO CONTINUE
C.R.T. TEST 2/2
PRESS TEST BUTTON TO EXIT
