C. DRIVE BOARD TEST
Select DRIVE BOARD TEST to display
the following screen.
This performs an operation to initialize the
Steering
Wheel motor, so make sure that
you do not touch the Steering Wheel.
Once the initialization operation is
complete, the following screen is displayed
where you can view the status of the
Steering
Wheel motor.
Press the SERVICE Button and move the
cursor to the item you want to update, then
press the
TEST Button to operate.
● STOP MOTOR: Halts motor activity.
● ROLL RIGHT: Rotates steering wheel completely to the right.
● ROLL LEFT: Rotates steering wheel completely to the left.
● CENTER OF STEER: Steering wheel motor's center of control is displayed.
(Default setting: 128)
• RIGHT
: Moves center of control position to the right.
• LEFT: Moves center of control position to the left.
● MOTOR POWER: Sets the steering resistance.
There are four levels to choose from, 100% (strong resistance), 90%, 80%,
and 60%(weak resistance). (Default setting: 80%)
After changing the settings, select EXIT
and press the TEST Button to return to the Game Test Menu
screen.
DRIVE BOARD TEST
STOP MOTOR
ROLL RIGHT
ROLL LEFT
CENTER OF STEER 128
:RIGHT
:LEFT
MOTOR POWER 80%
--> EXIT
SELECT WITH SERVICE BUTTON
AND PRESS TEST BUTTON
FIG. 9. 3 c b DRIVE BOARD TEST screen
FIG. 9. 3 c a DRIVE BOARD TEST screen
DRIVE BOARD TEST
Initializing the drive board
Please DO NOT touch the steering wheel.
To Next Page
