9. EXPLANATION OF TEST AND DATA DISPLAY
Periodically use the TEST Button and SERVICE Buttons inside the cabinet to perform operation tests and check data. When fi rst installing the game, when
collecting takings from it and if the game is not working properly follow the guidelines in this chapter to check it.
The chart below tells you which test screen to use under what kind of circumstances. This product uses the LINDBERGH game board and the DVD drive.
This system allows a different game to be used by changing the DVD disk in the DVD drive.
Therefore this product has two TEST Modes. The SYSTEM TEST Mode is for testing system functions such as coin settings that are common no matter the
software being used. The GAME TEST Mode has input tests specifi cally for the software being used, game diffi culty settings etc.
TABLE 9 TEST Modes
ITEM
DESCRIPTION
REFERENCE SECTION
INSTALLATION
OF MACHINE
When first installing the machine you must
perform the following.
1. Check the Information Display screen is
displayed correctly.
2. Test all input devices on the Input Test
screen.
3. Test all output devices on the Output Test
screen.
9-2a, b, c
9-2c, 9-3a, d, e
9-2d, 9-3b
PERIODICAL CHECK
CONTROL PROBLEM
MONITOR
IC BOARD
DATA CHECK
Perform the following checks periodically.
1. A check of all settings.
2. Test all input devices on the Input Test
screen.
3. Test all output devices on the Output Test
screen.
1. Test all input devices on the Input Test
screen.
2. Adjust or exchange the input devices.
3. If the problem remains check the
mechanical functions of each input device.
Use the Monitor Adjustment screen to check
that the monitor (projector) is adjusted
correctly.
1. Information display screen
2. Speaker Test
Check such data as game play time and
histogram to adjust the difficulty level, etc.
9-2f, 9-3c
9-2c, 9-3a, d, e
9-2d, 9-3b
9-2c, 9-3a, d, e
9-3d, e
Section 10
9-2d, Section 11
9-2a, b, c
9-2e
9-3f
