Segway MAX User Manual

10 / 14
5
S5-L
16
wrench head18#
6
T10hollow-S
17
wrench head26#
7
T15hollow-L
18
Wrench lever_25N.M
8
T20hollow-S
19
Wrench lever_100N.M
9
T25hollow-S
20
Valve tools_1
10
T30hollow-S
21
Valve tools_2
11
T45hollow-S
22
Valve tools_3
3.2 Regular check list
You can download the full checklist in our customer support system here.
3.3 Replacement of common parts
List of Max SOP
NO.
Name of SOP
NO.
Name of SOP
1
SOP of Display Incompletely
9
SOP of Replacing Rear Wheel
2
SOP of the Throttle cannot Rebound
10
SOP of Replacing Rear Fender Assembly
3
SOP of Shaking on Front/Rear Wheel
11
SOP of Solving Shaking in Riding
4
SOP of Replacing Battery
12
SOP of Replacing Controller
5
SOP of Replacing Built-in Charger
13
SOP of Front Tube Shaking in Riding
6
SOP of Replacing Display
14
SOP of Unable to Boot
7
SOP of Replacing Display Cover
15
SOP of Flat Tire Inspection
8
SOP of Replacing Fore Wheel
3.4 Failure Diagnosis
You can view the full list of Error Codes, their problem description and their solutions in our customer support
system here.
Table of Error code
Diagnostic index
Problem description
Diagnostic index
Problem description
MAX-10
Communication abnormality
between the display and the main
control board
MAX-26
Flash saves error
MAX-11
Motor A-phase current sampling
abnormality
MAX-27
Wrong main control board password
MAX-12
Motor B-phase current sampling
abnormality
MAX-28
Motor driven MOS upper bridge short
circuit
MAX-13
Motor C-phase current sampling
MAX-29
motor driven MOS under bridge fault

Segway MAX Specifications

General

Top Speed	18.6 mph (30 km/h)
Motor Power	350W
Battery Capacity	551 Wh
Weight	41.2 lbs (18.7 kg)
Max Load	220 lbs (100 kg)
Charging Time	6 hours
Tire Size	10 inches
Tire Type	Pneumatic
Water Resistance	IPX5
Foldable	Yes
Display	LED
Lights	Front and rear LED lights
Range	40.4 miles (65 km)
Brake Type	Front Drum Brake, Rear Electronic Brake
