2. Battery and charging
2.1 Battery parameter
Item
parameter
Rated voltage
36V
Maximum charging pressure
42V
Rated capacity
15300mAh/551Wh
Cycle times
500times, remaining
capacity>70%
2.2 Charging
Your scooter is fully charged with the LED on the charger changes from red (charging) to green (trickle green),
it will take 4 hours for charging fully. When charging, the screen on the battery will display different color;
when not charging, press the button for 2 seconds to display remaining power. And the display will show the
battery level when charging.
2.3 Charging precaution
1) Lithium Battery Product needs to charge regularly. Use the charger for Model Max to charge
the scooter when the power level is low.
2) Fully charge the scooter and reset the scooter to transportation mode before keep in store house longer
than one week. Recharge when battery level is low. Over Discharge will bring the unrecoverable damage
to your battery.
3) Do not leave scooter charger or single battery without your awareness.
4) Recommended Recharge Frequency as following if stored in the recommended Temperature Range.
Aged battery requires recharge more frequently, shorter time period for older battery.
Scooter or the Battery
Recharge

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Segway MAX and is the answer not in the manual?

Segway MAX Specifications

General IconGeneral
Top Speed18.6 mph (30 km/h)
Motor Power350W
Battery Capacity551 Wh
Weight41.2 lbs (18.7 kg)
Max Load220 lbs (100 kg)
Charging Time6 hours
Tire Size10 inches
Tire TypePneumatic
Water ResistanceIPX5
FoldableYes
DisplayLED
LightsFront and rear LED lights
Range40.4 miles (65 km)
Brake TypeFront Drum Brake, Rear Electronic Brake
