13
1 POWER Switch
The POWER Switch turns the power on or off.
The POWER LED lights when turning on the
power. To turn off the power, hold down the
switch for longer than 1 second.
2 FEED Switch
The FEED Switch operates paper feed. When
holding down the switch for a few seconds, the
printer feeds the thermal paper continuously for
the period of held.
3 ERROR LED
The ERROR LED lights when something is
wrong with the printer. For more details, see "7.
LED DISPLAY OF PRINTER".
4 POWER LED
The POWER LED lights when turning on the
power. For more details, see "7 LED DISPLAY
OF PRINTER".
5 Charging terminal
The terminal is for charging the battery pack by
using the optional cradle. DO NOT touch this
charging terminal.
6 USB connector
This connector is for charging without the cradle,
or using USB interface.
7 Paper cover open button
The button is for opening the paper cover.
8 Paper cover
The platen is released from the thermal paper
when opening this cover. Open this cover when
replacing the thermal paper or cleaning the
thermal head.
9 Paper outlet
Thermal paper is ejected from here. Two paper
cutters are installed: one is on the printer side,
and the other is on the paper cover side (9a, 9b).
Be careful not to touch these paper cutters.
10 Paper holder
The paper holder holds the thermal paper.
11 Thermal head
The thermal head prints data on the thermal
paper. NEVER touch the thermal head with
hands immediately after printing because it may
get hot.
12 Platen
The platen brings the thermal paper into contact
with the thermal head. The platen is turned to
feed the paper.
13 Paper sensor
The sensor detects thermal paper presence.
14 Battery cover
Open this cover when replacing the battery pack.
For more details, see "15. REPLACING
BATTERY PACK".
15 Belt clip
The belt clip is used for hooking to your belt to
carry the printer.
