33
13. ATTACHING/DETACHING BELT CLIP
The belt clip convenient for carrying the printer can be attached to this printer.
The belt clip is already attached to the printer at the factory shipment.
When using the printer as a stand-alone type, detach the belt clip, attach the spacer that is an
attachment of the cradle, and fix the printer to the cradle. For more details, see "14. ATTACHING
CRADLE".
Attaching/Detaching Belt clip
The belt clip is fixed to the printer with a screw (at 1 place).
To detach the belt clip, remove the screw from the printer.
To attach the belt clip, align the belt clip with the screw hole of the belt clip attaching part, and fix it with
the screw.
Figure 13-1 Attaching/Detaching Belt Clip
To Next Page
