0000137630 Rev. 2.0 12
!
Case Batch Mode:
Pump doses the selected quantity when UP button is pressed or when a pulse is read on input (other pulses are
ignored when pump is dosing) or if trigger/s signals are selected, when a valid trigger/s signals is read on input.
If time selected for dosing is too short, pump doses at the maximum flow rate.
The pump doses in proportion to an external signal (i.e.:
impulse launch counter). In this case, it is possible to set
the quantity to be dosed in l and the time within which to
complete dosage.
Dosage can be started manually by pressing the
key,
or by using a remote control. The
key interrupts
dosage. The dosage already made can be reset by
pressing the
key, or started again by pressing the
key again.
The quantity to be dosed can be modified during operation,
by pressing the
keys at the same time to
increase the flow, or the
keys to decrease.
Makes it possible to set:
• Time= the time within which to complete dosage in
second
• Qty= the quantity to be dosed in liter
