14. HANDLING
Hose replacement:
Release the cover by pulling the
left connector upward.
Position the roller at 20 past 10,
turning it in the direction of the
circular arrow.
Completely release the left
connector, holding it taut towards the
outside, and turn the roller in the
direction of the circular arrow so that
the hose is freed up to the right
connector.
Position the roller at 20 past 10,
turning it in the direction of the
circular arrow.
Insert the left connector into the
relative housing and pass the
hose under the roller’s guide.
Turn the probe holder in the
direction of the circular arrow,
simultaneously accompanying
the hose into the pump’s head,
until the right connector is
reached.
Arrows indicating the liquid’s
direction
Position the pump’s cap,
according to the direction of the
arrows (▲▼) and press its
surface hard so that it is
properly locked into place.
