Sekonic DIGITALMASTER L-758DR User Manual

-1-
HSILGNE
1. Parts Designation
Flash Synchro terminal
Lumisphere
Average / Δ EV (Brightness Difference)
button
Jog Wheel
ISO 2 button (“B” in radio channel setting)
ISO 1 button
(“A” in radio channel setting)
Mid-Tone button
("C" in radio channel setting)
23 Memory Clear button
(“D” in radio channel setting)
Memory button*
Lumisphere retracting ring
Measuring button*
Battery Cover Latch
Battery Compartment
18 Spot Lens
Power button
(ON/OFF switch)
Liquid Crystal Display (LCD)
19 Incident/Reflected Spot
Selector Dial
Strap eyelet
Battery Compartment Cover
25 Connector cover
RT-32CTL Radio
transmitter module
21 USB Port
Mode button
1. Light Meter Parts
L-758DR
L-758D/L-758CINE
*Measuring button and memory button can be
swithced in Custom settings.
22 Eyepiece (with Diopter
Adjustment)
24 1/4” Tripod Socket
