Metering
The SEL-2414 provides extensive metering capabilities. See Specifications for metering and power measurement
accuracies. As shown in Tab le 1, metering includes current and voltage based metering and analog input, math variable,
and remote analog metering. Fundamental, maximum and minimum, and demand metering typically includes phase
voltages and currents; sequence voltages and currents; and power, frequency, and energy.
Additional Ordering Options
The following options can be ordered for any SEL-2414 model:
Ta bl e 1 M e te r in g Ty pe s
Standard
Fundamental IA, IB, IC, VA, VB, VC
Energy Real and Reactive (In and Out)
Maximum and Minimum Frequency, Voltages (VA, VB, VC), Currents (IA, IB, IC, 3I2), Reactive, and Real Power
Demand and Peak Demand IA, IB, IC, IG, 3I2
Analog Input AIx01–AIx08
Math Variable MV01–MV32
Remote Analog RA001–RA128
Analog Signal Profiling
Optional
➤ Temperature and thermal (with the external SEL-2600 RTD Module, internal RTD option, or internal RTD/TC option)
➤ Maximum and Minimum Temperatures
Digital I/O
a
8 DI, 14 DI, 8 DO, 4 DI/4 DO, 4 DI/3 DO with 2 Form C and 1 Form B
Analog I/O 8 AI, 4 AI/4 AO
Temperatures 10 RTDs
CTs and PTs 3 ACI/3 AVI, 4CT, 3 AVI
Port 1 Single/Dual 10/100BASE
-T copper (RJ45 connector)
Single/Dual 100BASE FX (LC connector)
Port 2 Fiber-Optic Port (62.5 µm core fiber, ST connectors, SEL
-2812 compatible)
Port 4 EIA
-232 or EIA-485 (PN 9751)
Protocols Serial: DNP3; Ethernet: Modbus TCP, DNP3 LAN/WAN, FTP, Telnet, IEC 61850
Mounting Surface Mounting kit for in-cabinet installation (PN 915900204)
Environment Conformal coating for chemically harsh and high-moisture environments
a
Unless otherwise specified, all digital outputs are Form A.
