10
D) Clamp on Balcony Type
12
3
S2
S5
S5
S2
S6
S6
N1
N1
N1
B1
B6
B5
B5
B2
B2
A1
S2
S3
2
4
5
Step 3: Connecting the Antenna and the Set top box
Once you have installed the antenna in an open loop space and mounted the way you want it to be the
next step is to connect it all together.
In order to be able to watch your favorite satellite programs, you need to connect your satellite antenna
to a receiver by a cable.
The cable between the antenna and the Satellite receiver should not exceed 30m as it will decrease the
quality of the signal.
The use of a long or bad quality cable and not isolated jacks can cause a loss of the signal level, it would be
preferable to use an RG6 Coaxial cable (HF 17VATC or 19VATC cable), in order to minimize a signal loss.
