Page #6 background imageLoading...
Page #6 background image
5
No
1 1
SELFSAT-H21DSELFSAT-H10D
Antenna
Body
2 1
Attenuation
PAD
AT-PAD
AT-PAD
3
A1
P1
B1 1
Angle
Bracket
4B2 1
Main
Support
5B3 1
Window
Bracket A
6B4 1
Window
Bracket B
Fix
Bracket A
Fix
Bracket B
7B5 1
8B6 1
Symbol Part name Image Quantity
9B7 1
Spanner
Box Content
SELFSAT-H10D/H21D
