11
ENGLISH
S4
B3
B2
Slightly loosen the M6 Knob Nut
Slide the folded Multi-Functional Base into the suction cup set to the end (see red arrow below)
3)
4)
Tighten the M6 Knob Nut to fasten the Multi-Functional Base on the suction cup
Insert the Dish-Set onto the Multi-Functional Base and tighten the M6*25mm Knob Screw
5)
6)
M6 x 25mm
Knob Screw
