SELFSAT H30D - C) Installing and Fixing the Base of the Camping Set

7
ENGLISH
C) Installing and xing the base of the camping set
Type 1
Take the folded Multi-Functional Base on the table
Putt he long side of L-Type Bolt into the Fix Plate and the short side into the Multi-Functional
Base
1)
2)
B2
B4
Use the M8 Knob Nut to fasten the Fix Plate and the Multi-Functional Base
Insert the Dish Set onto the Multi-Functional Base and M6*25mm Knob Screw to fasten the
Camping-Set on the table
3)
4)
S5
S1
S1
M6 x 25mm
Knob nut
B2
B4
