SELFSAT H30D User Manual

8
Type 2
Put the folded Multi-Function Base along a mast and insert the U-Type Bolt into the
Multi-Functional Base. Then use two M6 Knob Nuts to fasten the Multi-Functional Base on the
mast.
Insert the Dish Set onto the Multi-Functional Base and use M6*25mm Knob Screw to fasten the
Camping-Set.
1)
2)
B2
Type 3
Take the open Multi-Functional Base and slightly loosen the M6*25mm Knob Screw
Insert the Dish-Set onto the opened Multi-Functional Base. Then tighten the M6*25mm Knob
Screw
1)
2)
S3
S4
S2
B2
B2
B1
A1
M6 x 25mm
Knob Screw
M6 x 25mm
Knob Screw
