D) Adjusting azimuth and elevation
With opened Multi-Functional Base
- Find the suitable azimuth and tighten the M6*25mm Knob Screw to fasten AZ/EL
Adjusting the azimuth
A.
With folded Multi-Functional Base
- Find the suitable azimuth and tighten the M6*25mm Knob Screw to fasten AZ/EL
B.
M6 x 25mm
Knob Screw
M6 x 25mm
Knob Screw
