ENG
SETTING MANUAL
16
Menu navigation
In menu have keys new meaning, marked bellow them (Picture
12). To move between the groups press key to move to the
left and key to move to the right (Picture 12). To move within
the group press key to move down between the lines and
key to move up between the lines. For your better understanding
are all the lines marked. First two symbols mark the group and
the third symbol successive number of the line in group (Picture
13).
All data and parameters are joined into 4 groups:
d1 ·············· room unit data
P1 ·············· basic parameters
S1 ·············· service parameters
S3 ·············· service parameters
Menu
To enter menu hold key and press key (Picture 11).
Release keys after you hear a beep. The display writes out first
group d1.
Menu
Picture 11
Picture 12
Move to the left
Move to
the right
Move up
or increase
Move down
or decrease
