| 15Instructions for use
EN
ADDITIONAL AND
SERVICE SETTINGS
INFORMATION GROUP T1 - TEMPERATURES
No. Description
t1.1
T1 CONTROLLER SENSOR
Measured and calculated temp. for T1 sensor are displayed alternately.
t1.2
T2 CONTROLLER SENSOR
Measured and calculated temp. for T2 sensor are displayed alternately.
t1.3
T3 CONTROLLER SENSOR
Measured and calculated temp. for T3 sensor are displayed alternately.
t1.4
T4 CONTROLLER SENSOR
Measured and calculated temp. for T4 sensor are displayed alternately.
t1.5
T5 CONTROLLER SENSOR
Measured and calculated temp. for T5 sensor are displayed alternately.
t1.6
T6 CONTROLLER SENSOR
Measured and calculated temp. for T6 sensor are displayed alternately.
t1.7
T7 CONTROLLER SENSOR
Measured and calculated temp. for T7 sensor are displayed alternately.
t1.8
T8 CONTROLLER SENSOR
Measured and calculated temp. for T8 sensor are displayed alternately.
t1.9
T9 CONTROLLER SENSOR
Measured and calculated temp. for T9 sensor are displayed alternately.
t1.10
T10 CONTROLLER SENSOR
Measured and calculated temp. for T10 sensor are displayed alternately.
t1.11
T11 CONTROLLER SENSOR
Measured and calculated temp. for T11 sensor are displayed alternately.
t1.12
T12 CONTROLLER SENSOR
Measured and calculated temp. for T12 sensor are displayed alternately.
t1.13
THE FIRST HEATING CIRCUIT TR1
Measured and requested room temp. of the first heating circuit are displayed
alternately.
t1.14
THE SECOND HEATING CIRCUIT TR2
Measured and requested room temp. of the second heating circuit are dis-
played alternately.
t1.15
DIRECT CIRCUIT
Calculated temp. of the riser for direct circuit is displayed.
