4. Bill of Materials
Table 4-1: Bill of Materials
Quantity Reference Part
5 C3, C18, C40, C86, C103 22μF Capacitor (805)
5 C8, C20, C23, C24, C30 10nF Capacitor (0603)
9 C9, C10, C21, C22, C25, C26, C31, C87, C90 1μF Capacitor (0603)
18 C11, C12, C13, C14, C15, C16, C17, C27, C28,
C29, C32, C33, C34, C35, C47, C48, C57, C85
10nF Capacitor (0402)
1 C36 EEV-FK1C221XP
(CT-CAP/PANA_FK_D8)
2 C39, C88 33μF Capacitor (1210)
1 C41 47nF-470nF Capacitor (0402)
3 C42, C49, C51 1μF Capacitor (0402)
2 C43, C44 16pF Capacitor (0603)
2 C50, C52 4.7μF Capacitor (0603)
10 C58, C63, C65, C70, C84, C91, C92, C93, C94,
C95
0.1μF Capacitor (0402)
2 C100, C101 470nF Capacitor (0402)
2 D11, D102 LNJ311G8PRA (1206_LED)
2 D100, D101 CT-S
MB_DO214AA
1 F101 0603L035 (CT-0603)
1JP1 TSW-105-07-L-D (BLKCON
.100/VH/TM2OE/W.200/10)
1 JP4 JUMPER (HEADER_.100_1X2)
1JP7 BLKCON
.100/VH/TM1SQ/W.100/3
2J4, J5 UCBBJE20-1 (BNC_EDGEMNT
_GHZ-POUR-2LYR-ER3.8)
1J16 TMMH-124-01-F-D-RA-ES
(HEADER2MM_48_2X24)
2 J17, J18 TMMH-105-01-F-D-RA
(HEADER2MM_10_2X5)
4 J19, J20, J21, J22 BCJ-FPLV01 (BNC
_EDGEMNT_RIGHT_ANGLE)
1J23 TSW-105-07-L-D
(HEADER2MM_10_2X5)
1 J24 5V Input
(CON_WEID5MM_2_PWR)
1L3 6.2nH Inductor (0402)
