Semtech EB-GS2971 - Evaluation Board User Guide 52169 - 2 June

EB-GS2971
Evaluation Board User Guide
52169 - 2 June 2012
20 of 22
Proprietary & Confidential
1L4 5.6nH Inductor (0402)
2 RN1, RN2 742C163220 (CT-742_16)
1 RN3 742C163103 (CT-742_16)
7 R2, R9, R10, R11, R12, R91, R94 0Ω Resistor (0603)
1 R3 3.57kΩ Resistor (0603)
2R6, R84 1.15kΩ Resistor (0603)
1 R7 105Ω Resistor (0603)
10 R14, R16, R17, R18, R20, R22, R24, R25, R37,
R38
22Ω Resistor (0402)
7R35, R36, R87, R88, R89, R90, R93 10kΩ Resistor (0402)
1 R40 750Ω Resistor (0402)
8 R41, R42, R43, R44, R45, R47, R85, R86 75Ω Resistor (0402)
1R46 37.4Ω Resistor (0402)
2 R48, R49 49.9Ω Resistor (0402)
2 R57, R100 240Ω Resistor (0603)
1 R92 10kΩ Resistor (0603)
1R96 49.9kΩ Resistor (0603)
1 SW2 Switch, DIP-10/SM (Through
Hole)
1 SW100 Switch,
SLIDE-DP3T
1 S1B3S-1002P
6 TP2, TP7, TP8, TP18, TP19, TP20 Via (CT-TP)
1U1 MAX6823V (SOT23-5)
1U4 MCP1725-1202E/SN (CT-SOIC_8)
1U5 GS2971 Receiver
(CT-BGA_100_11X11_1.00)
1U7 GS2978 Cable Driver
(CT-QFN_4MM_16/WSHLD)
2 U12, U13 HSMF-C165
1 U14 TPS74201_RGW (20-QFN)
1U15 SN74LVC1T45DBVR (SOT23-6)
1U16 FXL4TD245 (DQFN-MLP016E)
4 U17, U18, U19, U20 SN65LVDT2 (SOT23-5)
1 U22 TPS77518D (CT-SOIC_8)
Table 4-1: Bill of Materials (Continued)
Quantity Reference Part
