Senco SCP40XP - Technical Specifications; Fastener Specifications

11
Technical Specifications
Technical SpecificaTionS
Minimum to maximum operating pressure 80 - 120 psi 5.5 – 8.3 bar
Air Consumption (60 cycles per minute) 5.20 scfm 147,2 liter/min.
Air Inlet 3/8" NPT 3/8" NPT
Weight 7.1 lbs. 3,22 Kg
Fastener Capacity 42 42
Tool size: Height 12.22" 310,4 mm
Tool size: Length 18.21" 462,5 mm
Tool size: Width: Main Body 4.5" 114,4 mm
Maximum Fastener Size 1 1/2" (38 mm) Length x .109" (2,8 mm) dia. shank
Fastener Specifications
A
0.104"/0.118"
A
0.109"
A
0.109"
A
0.109"
A
0.109"
Senco
faSTener code
a
incheS MM
W3050YXC 1/2
12,7
W3075YXC
3/4 19
W3100YXC
1 25,4
W3125YXC
1 1/4 31,8
W3150YXC
1 1/2 38,1
Head Diameter = 0.250" / 6,4 mm
