CENTRAL ROTARY BRUSH
■ Push on the latches G2 of the central rotary brush cover G1 and take the cover out
together with the brush.
■ Use adry wiping cloth to clean out the compartment G5 in which the rotary brush
is housed. Also clean the suction hole, the procedure is described later in this
user'smanual.
■ Remove any dirt and material (dust, wound on hair, animal fur, etc.) from the rotary
brush G3 and the bearings G4. You can cut heavily wound on hair using the blade
H2 of the cleaning brush.
■ Reinsert the rotary brush and its cover.
Attention:
In the event that an excessive amount of dirty material
accumulates on the central rotary brush and in its compartment,
there is a risk of permanently damaging the vacuum cleaner.
Regularly inspect the condition of the brush.
Do not use the vacuum cleaner without the central rotary brush.
■ When using the rubber rotary brush G6 instead of brush A14, proceed in the same
manner when cleaning it.
SUCTION HOLE
■ The suction hole is located underneath the central rotary brush, therefore, take it out
before cleaning the suction hole as described in the previous chapter. With repeat
use, dust and dirt may accumulate around the suction hole, which may manifest
itself through decreased suction efficiency. Remove the dirt and dust from the
suction hole using asoft brush. Regularly clean the suction hole to ensure maximum
suction power.
SIDE ROTARY BRUSH
■ Take out the rotary brush A11 by pulling it upwards. Remove any dust and dirt from
the location where the brush was mounted.
■ Remove all dust and dirt from the brush. If necessary you may wash the brush under
running water. If the bristles were deformed while the vacuum cleaner was running,
dip them in warm water to allow them to return to their original shape. Allow the
brush to dry before reattaching to the vacuum cleaner.
■ After cleaning it, reattach it.
Note:
The rotary brush wears out with use. After acertain time it is necessary to
replace the worn out brush with anew one. To order anew brush, contact
your vendor or an authorised service centre.
COMPLETE ROBOTIC VACUUM CLEANER
■ Regularly wipe the surface of the vacuum cleaner using asoft dry wiping cloth.
■ First remove any coarser dirty material from the front swivel wheel A16 and the
motorised wheels A13 and A19. Then clean them around their entire perimeter
using alightly dampened cloth and wipe them dry. Do not forget to also clean the
area around the wheels.
■ At least once per week, or more often, wipe the sensors A10, A12, A17 on the
underside of the vacuum cleaner and the side sensor A7 using asoft dry wiping
cloth or acotton bud.
■ Regularly clean the vents A8 along both sides of the vacuum cleaner.
CHARGING STATION
■ At least once per week, clean the surface of the charging station B2 including the
charging contacts B3 using asoft dry wiping cloth.
STORAGE
When not using the vacuum cleaner for an extended period of time, do the following:
■ Hold down button A5 (
) to turn off the vacuum cleaner.
■ Clean the vacuum cleaner as described in chapter CLEANING AND MAINTENANCE.
■ Disconnect the charging station from the power socket.
■ Store the vacuum cleaner with all its accessories in adry, clean and cool place.
TECHNICAL SPECIFICATIONS
Robotic vacuum cleaner
Dimensions (diameter × height) ................................................................................355 × 95 mm
Weight ................................................................................................................................................3.8 kg
Motor power output .......................................................................................................................65 W
Operating time per single charge ........................................................................... up to 200 min
Dust container capacity ............................................................................................................ 480 ml
Water tank capacity .....................................................................................................................260 ml
Capacity of dust container inside the water tank .............................................................240 ml
Vacuuming system..................................................................................SUPER CYCLONE 8 000 Pa
Navigation system ....................................................................................................Sencor Nav. 18.0
Power adapter
Input ....................................................................................................100–240 VAC, 50/60 Hz, 0.2 A
Output .................................................................................................................................5 V, 1,000 mA
Battery
Type ............................................................................................................................. 6,200 mAh Li-Ion
Charging time .................................................................................................................................. 4–6 h
Input ................................................................................................................................................. 5 V, 1 A
The declared noise emission level is lower than 69dB(A), which represents alevel Aof
sound power with respect to areference sound power of 1pW.
DISPOSAL OF USED BATTERIES
■ Prior to handing over the product at aspecialised collection facility, it is necessary
to ensure that the battery is removed. Prior to removing the battery, turn off the
vacuum cleaner using the main switch. Disconnect the battery according to the
procedure described in chapter REPLACING THE BATTERY.
This symbol indicates that used batteries do not belong in ordinary
municipal waste. Hand over used batteries to designated collection
points for proper disposal. Correct disposal of batteries will help
prevent negative impacts on the environment and human health.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of
used batteries, request the necessary information about the correct
disposal method from the local authorities or from your vendor.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling, hand
these products over to determined collection points. Alternatively, in
some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human health, which
could result from improper waste disposal. Ask your local authorities or collection
facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic devices, ask your retailer or supplier for
the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This product meets all the basic requirements of EU directives related to
it.
SENCOR hereby declares that radio device model number SRV 9550BK is in compliance
with directive 2014/53/EU. The full wording of the EU Declaration of Conformity is
available at the website: www.sencor.eu.
