Doc# 2016-25-05 Rev F Technical Support 678-208-3087 Ext #1 Airtext Installation Manual

Recommended Crimp Tools

Wire Gauge Hand Crimping Tool 20-24 AWG

Positioner

Insertion Extraction Tool

Military P/N M22520/2-01 M22520/2-09 M81969/1-04

Positronic 9507 9502-4 M81969/1-04

Amp 601966-1 601966-6 91067-1

Daniels AFM8 K42 DAK95-22MB/ DRK95-22MB

Astro 615717 615725 M81969/1-04

NOTE

Non-Send Solutions part numbers shown are not maintained by Send Solutions and are subject to change

without notice.

Cabling and Wiring

Wiring should be installed in accordance with AC 43.13-1B Chapter 11. When wire separation cannot be

achieved, the following issues should be addressed:

• The cable harness should not be located near flight control cables, high electrical capacity lines, or fuel

lines.

• The cable harness should be located in a protected area of the aircraft.

• Do not route cable near high-energy sources.

See the interconnection diagrams in Figure 2 for the appropriate wiring. Once the cable assemblies have

been made, attach the cable connector. Route the wiring bundle as appropriate. Avoid sharp bends.

For Airtext, use 22 AWG or 20 AWG wire for all connections including power/ground.

CAUTION

Check wiring connections for errors before connecting the 25-pin D-sub to Airtext. Incorrect wiring could

cause component damage.
