Doc# 2016-25-05 Rev F Technical Support 678-208-3087 Ext #1 Airtext Installation Manual
Technical Specifications
Physical Characteristics
Specification Airtext Airtext +
Operating Temperature Airtext -40C to +75C (At less than 75% RH) -40C to +65C (At less than 75% RH)
Storage Temperature -40C to +85C (At less than 95% RH) -40C to +85C (At less than 95% RH)
Operating Voltage +11 VDC to +32 VDC +11 VDC to +32 VDC
Operating Current .276 Amps @ 12 Volts, and .12 Amps
@ 28 Volts
.276 Amps @ 12 Volts, and .12 Amps
@ 28 Volts
Inrush Current 10 Amps for 8uS @ 28 Volts 10 Amps for 8uS @ 28 Volts
Size (Without antennas &
cables)
7.5” X 4.6” X 1.4” 7.5” X 4.6” X 1.4”
Weight Airtext 1 lb. 1 oz. 1 lb. 2 oz.
Materials Black Anodized Aluminum Black Anodized Aluminum
DO-160 Testing Section 16 Category Z, Section 21
Category M
Section 16 Category Z, Section 21
Category M
Antenna Connector TNC, Female Standard TNC, Female Standard
Bluetooth Specifications
Characteristics Specification
Bluetooth Version 4.1
Bluetooth Class 2.0
Maximum Transmitter Power 4 dBm (2.5 mW)
Effective unimpeded range 33 feet (10 m)
