Send Solutions AirText - CONNECTOR PINOUT INFORMATION

23
Doc# 2016-25-05 Rev F Technical Support 678-208-3087 Ext #1 Airtext Installation Manual
CONNECTOR PINOUT
INFORMATION
Table 6-1 Airtext Pinout List
Pin #
Airtext
Airtext +
I/O
1.
Aircraft Power
Aircraft Power
(Plus)
In
2.
Aircraft Power Retur
n (Minus)
Aircraft Power Return (Minus)
--
3.
Digital Input
#
1
Digital Input
#
1
In
4.
Digital Output
Digital Output
Out
5.
Reserved
Reserved
--
6.
ARINC RX 1 A
ARINC RX 1 A
In
7.
ARINC RX 2 A
ARINC RX 2 A
In
8.
Ground
Ground
--
9.
CAN Bus High 1
C
AN Bus High 1
In
10.
CAN Bus High 2
CAN Bus High 2
In
11.
RS
-
485 A/ RS
-
232 TX
RS
-
485 A/ RS
-
232 TX Port 1
Out
12.
Reserved
RS
-
485 A Port 2
Out
13.
Ground
Ground
--
14.
Reserved
Reserved
--
15.
Reserved
+5V Output (.25 Amp Max)
Out
16.
Digital Input #
2
Digital Input #2
In
17.
Digital Input #3
Digital Input #3
In
18.
Reserved
Reserved
--
19.
ARINC RX1 B
ARINC RX1 B
In
