USER MANUAL – Z-SG
12
10. Measure Calibration with Modbus Registers
10.1. CALIBRATION WITH EASY SETUP
Factory calibration
Calibration with Standard weight
Factory calibration using calibration button (or digital input in Z-SG model)
Calibration with known weight using calibration button (or digital input in Z-SG model)
LOAD CELL SENSITIVITY (Dip-Switches: SW2)
6
7
8
Meaning
±1 mV/V
±2 mV/V
±4 mV/V
± 8mV/V
±16 mV/V
±32 mV/V
±64 mV/V
The module acquires load cell sensitivity from register 40044, 40045 (FP): in this case,
real numbers for sensitivity are allowed
RS485 TERMINATOR (Dip-Switches: SW3)
1
2
Meaning
RS485 terminator disabled
RS485 terminator enabled
