Putting the MK 4 into operation
Connecting the microphone
왘 Use a microphone cable with XLR-3 female connector to con-
nect the microphone’s XLR-3 male connector to the microphone
preamplifier (48 ± 4 V phantom powering as per IEC 61938, at
least 3.5 mA per channel).
Pin assignment of the XLR-3 connector
CAUTION! Damage to the product due to an unsuitable power
supply!
An unsuitable power supply can cause damage to
the product.
왘 Only connect the product to microphone inputs
or power supply units which provide 48 V phan-
tom powering as per IEC 61938.
12
3
1
2
3
+
+
XLRXLR
12
3
XLR
+
+
