Sennheiser MKH 416 - Specifications; Polar Diagram; Frequency Response Curve

MKH 416|3
Specifications
Polar diagram
Frequency response curve
The original measurement protocol is included with each microphone,
measured from 50 to 20,000 Hz.
Frequency response 40 ... 20,000 Hz
Transducer principle RF condenser microphone
Pick-up pattern super-cardioid/lobar
Sensitivity (free field, no load)
(1 kHz)
25 mV/Pa ±1 dB
Nominal impedance 25
Ω
Min. terminating impedance approx. 800 Ω
Equivalent noise level
CCIR-weighted (CCIR468-3)
A-weighted
approx. 24 dB
approx. 13 dB
Max. sound pressure level 130 dB SPL
Power supply 48 V ± 4 V phantom powering
Current consumption approx. 2 mA
Temperature range –10 °C to +70 °C
Finish matt black
Connector 3-pin XLR connector
Pin assignment 1: Ground, housing; supply (–)
2: AF (+); supply (+)
3: AF (–); supply (–)
according to IEC publication
268-14/2
Dimensions
∅ 19 x 250 mm
Weight 175 g
30°30°
0°
0
5
10
15
20
25
dB
60°60°
90°90°
120°120°
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
150°150°
180°
1.00
dB V
-20
-30
-40
-50
-60
-70
50 Hz
100
100 Hz 200 Hz 500 Hz 1 kHz 2 kHz 5 kHz 10 kHz 20 kHz
Linear
„Low Cut“
