Sennheiser NET 1 - Advanced Connection Scenarios; Connecting EM 3532 Twin Receiver; Daisy-Chaining Multiple NET 1 Units

14
Connecting an EM 3532 twin receiver
왘 To connect an EM 3532 twin receiver to the sub-D socket  on the NET 1,
use only the right-hand (as viewed from the rear of the receiver) common
data interface DATA IN/OUT as shown in the diagram below.
Connecting several NET 1
왘 Connect two NET 1 via the sockets LAN 1  and LAN 2  using an
Ethernet cable. The sockets LAN 1 and LAN 2 are identical, so it doesn’t
matter in which order you connect them.
RX 1
RX 1
RX 2
RX 2
EM 3532
NET 1
 
