Overview of the TR 175 transmitter
SURR
LO
HI
BASS
1
2
4
9
7
5
6
8
0
3
1 TR status LED
2 BASS b
utton (with LED indica-
tor)
3 Virtual surround sound LED indi-
cators, low LO and high HI
4 SURR Virtual surround sound
butt
on
5 Charge status LED indicator
6 Charging contacts
7 DIGITAL OPTICAL IN Digital
optical audio inp
u
t
8 Input selection switch
9 ANALOG 3.5 mm IN Analog
audio in
put (3.5 mm jack)
0 DC 9V 0.3A socket for
the power
supply unit
