Sennheiser TR 185 - 3.5 mm;6.3 mm Jack Audio Connection

Putting the RS 185 into operation
RS 185 | 15
Connection option C: 3.5 mm or 6.3 mm/¼“ jack socket (analog)
Some TV models mute the loudspeakers when you connect the transmitter
to the headphone socket. Check in the m
enu of your TV to see if the muting
function can be deactivated. Alternatively, connect the TV and the trans-
mitter using a different option (A or B).
왘 Switch your audio source off befor
e conn
ecting the transmitter.
왘 Connect the RCA plugs to the RCA inputs of your transmitter. Connect
the red RCA
plug to the red RCA socket and the white RCA plug to the
white RCA socket.
왘 If necessary, connect the 6.3 mm/¼“ adapter
jack plug onto the
3.5 m
m plug of the RCA cable.
왘 Connect the 3.5 mm plug of the RCA cable to the headphone socket
of
your audio source.
C
Adjust the volume of the headphone socket on your audio source to
at least about the medium level.
Analog
* Cable and adapter not included
P
HO
N
ES
*
*
VOLUME
