E - 10
CONTROL REFERENCE GUIDE
1) / I button
2) PLAY button
3) STOP button
4) MENU button
5) FUNCTION button
6) CH buttons
button
button
7) – VOLUME + controls
8) Colour LCD Screen
9) Disc Door
10) button
11) Remote Sensor
Standby Indicator
12) Removable stand
13) Power Cord
14) AV OUT Video Output Jack
15) AV OUT Audio Output Jacks (Left/Right)
16) AV IN Video Input Jack
17) AV IN Audio Input Jacks (Left/Right)
18) HDMI IN jack
19) PC IN MONITOR/VGA Jack
20) PC IN Audio Jack
21) YUV IN Component Video Input Jacks (Y/PB/
PR)
22) YUV IN Audio Input Jacks (Left/Right)
23) AV IN S-Video Input Jack
24) Headphone Jack
25) TV Antenna Cable Terminal - Coaxial TV
Antenna Input
1
2
3
4
5
7
8
9
10
11
12
6
13 14 15 16 17
18 19 20 21 22 23 24 25
To Next Page
