MT4412E Rev.2 15/10/2019 Pagina 6 di 30
Gas control unit ordering codes and accessories
PL4 +D gas control panel.
4 Analog 4-20mA inputs and 6 relay outputs on-board the panel.
1 x RS485 type open bus line to connect additional 8 detectors through
remote 8-input module or addressable gas detectors daisy chained to the
RS485 bus.
5 relay outputs and additional 16 o/c via the dedicated STG/OUT16-S and
STG/8REL cards.
High safety 8-input remote module for PL4 +D control panel.
16 O/C card to be connected to PL4 +D to provide additional 16 outputs
Plug and play relay board to be connected to STG/OUT16 to provide 8 relay outputs
Power supply 24Vdc 2A for DIN plank.
IP65 plastic box, 12 module.
Windows PC software for PL4 +D control panel programming. Running under
Windows XP, VISTA, WIN7, 8, 8.1, 10.
The configuration software is supplied along with the control panel
