Sensitron PL4 +D - 1) Unit Diagram and Part Identification

MT4412E Rev.2 15/10/2019 Pagina 9 di 30
2.1.1) Unit diagram and part identification
5
4
3
2
1
1- Power Supply (24 Vdc)
2- Relay outputs (5)
3- USB port
4- RS485 bus connection
5- 4 inputs 4-20 mA
Fig. 2.1.1) Unit diagram and part identification
