Page 6
Take a Measurement in RUN Mode
When in RUN MODE, the reading continuously changes as the current on the
conductor changes. The unit is immediately in the RUN mode after powering on.
To place the instrument into the RUN mode from a different mode, press and hold
the control switch and scroll to the option RUN, then release the control switch to
engage the option.
Step 1: Attach the unit to a hot stick with a universal chuck adapter.
Step 2: Power on the unit by pressing and releasing the control switch.
STARTUP TEST
The Ampstik+ conducts a startup test to verify the sensor and circuitry
is functioning correctly. The following screens will display during the
test:
If the test detects a failure, the display will show FAIL and a
corresponding code as per below. See page 13 for the failure code
chart.
If the test determines the unit is functioning properly, it will move to
normal mode and is ready to take the fi rst measurement. The display
will show:
- - -
FAIL
1
0.0
