AUDIO
PAUSED
/AUDIO
OFF
Button
• to pause auditory alarm signals for 1 or 2 minutes
(depending on respective menu setting)
• to switch OFF auditory alarm signals permanently (by
pressing > 3 seconds)
Note: Switching off auditory alarm signals is only pos-
sible if enabled by the institution.
Note: This button is inactive if the menu parameter
‘Alarm Settings/Alarm Volume’ is set to OFF.
Enter
Button
• to activate the selected sub-menu or function
• to activate/deactivate ‘editing mode’ for the selected
menu parameter*
• to activate ‘Quick Access Menus’ (only if menu is not
open)
• to terminate the ‘Sensor off patient (8 )’** and ‘Remote
Monitoring Interrupted (8 )’ alarms
• to activate the second ‘System Information’ page (only
if first ‘System Information’ page is open)
Display
Button
• to toggle between the available measurement screens
• to deactivate ‘editing mode’ for the selected
menu-parameter*
• to exit the menu from any menu level (only if ‘editing
mode’ is inactive)
*For parameters that are highlighted with a blue menu bar in
‘editing mode’, changes become effective immediately without
confirmation (see example 1 below). For parameters that are
highlighted with a yellow menu bar in ‘editing mode’, changes
Menu/
Previous
Level
Button
• to activate the menu
• to return to the menu on the next higher level (only
if ‘editing mode’ is inactive, exits the menu if pressed
while at top level)
• to deactivate ‘editing mode’ for the selected
menu-parameter*
Note: Menu access can be disabled by the institution
(e.g. for home use)
UP
Button
• to select a menu-item by scrolling the blue menu bar
upwards through the menu (only if ‘editing mode’ is
inactive)
• to increase the value of the menu parameter for which
‘editing mode’ is active*
• to increase the brightness of the display (only if a
measurement screen is active)
DOWN
Button
• to select a menu-item by scrolling the blue menu bar
downwards through the menu (only if ‘editing mode’
is inactive)
• to decrease the value of the menu parameter for which
‘editing mode’ is active*
• to decrease the brightness of the display (only if a
measurement screen is active)
Controls, Indicators and Alarms
Controls (Buttons)
The ON/OFF switch is located on the rear panel of the SDM
24
. The following controls (buttons) are located on the front
panel of the SDM:
To Next Page
