45
Wire List: The following list defines every wire in the monitor. Abbreviations are
defined as follows:
P1 = Power Supply
F1 = Fuse Holder
TB1, TB2, TB3, TB4 = Terminal Board
K1, K2, K3, K4 = Relays
A1 = Control Board
A2 = IR Bench
A3 = Valve Driver Board
A4 = Keypad
A1-JPx = Connector on Control Board A1
Wire #
From To Type Description
1 TB1-1 GND 18 AWG ,Green/Yellow Earth Ground
2 TB1-1 PS1-GND 18 AWG ,Green/Yellow Earth Ground
3 TB1-1 Pump GND 18 AWG ,Green/Yellow Earth Ground
4 GND Door GND 18 AWG ,Green/Yellow Earth Ground
5 TB1-2 F1-1 22 AWG ,Black AC Line In
6 F1-2 TB1-4 22 AWG ,Black Fused AC Line
7 TB1-4 PS1-P1-L 22 AWG ,Black Fused AC Line
8 TB1-4 Pump Line In 22 AWG ,Black Fused AC Line
9 TB1-3 PS1-P1-N 22 AWG ,White AC Neutral
10 TB1-3 Pump Neutral 22 AWG ,White AC Neutral
11 PS1-P2-1 A1-P9-1 24 AWG, Red 24 VDC
12 PS1-P2-3 A2-SRC-P1-2 24 AWG, Blue 5 VDC
13 PS1-P2-4 A1-P9-3 24 AWG, Black DC Gnd
14 PS1-P2-5 A2-SRC-P1-1 24 AWG, Black DC Gnd
15 A3-J2 A1-PJ1 CAT 3 (6Cond.) Control Cable
16 A3-J3-1 A1-P9-4 24 AWG, Red 24 VDC
17 A3-J3-2 A1-P9-2 24 AWG, Black DC Gnd
18 A3-J3-3 A1-P5-3 24 AWG, Red 24 VDC
19 A3-J3-4 A1-P5-4 24 AWG, White Switched Gnd, Autozero Valve
20 A3-J4-1 Area 1 Gnd In 18 AWG, Black Part of Valve Assembly
21 A3-J4-2 Area 1 Power In 18 AWG, Black Part of Valve Assembly
22 A3-J4-3 Area 2 Gnd In 18 AWG, Black Part of Valve Assembly
23 A3-J4-4 Area 2 Power In 18 AWG, Black Part of Valve Assembly
24 A3-J4-5 Area 3 Gnd In 18 AWG, Black Part of Valve Assembly
25 A3-J4-6 Area 3 Power In 18 AWG, Black Part of Valve Assembly
26 A3-J4-7 Area 4 Gnd In 18 AWG, Black Part of Valve Assembly
27 A3-J4-8 Area 4 Power In 18 AWG, Black Part of Valve Assembly
28 A3-J4-9 Area 5 Gnd In 18 AWG, Black Part of Valve Assembly
29 A3-J4-10 Area 5 Power In 18 AWG, Black Part of Valve Assembly
30 A3-J4-11 Area 6 Gnd In 18 AWG, Black Part of Valve Assembly
31 A3-J4-12 Area 6 Power In 18 AWG, Black Part of Valve Assembly
32 A3-J4-13 Area 7 Gnd In 18 AWG, Black Part of Valve Assembly
33 A3-J4-14 Area 7 Power In 18 AWG, Black Part of Valve Assembly
To Next Page
