SenTech IR-SNIF-MCD Series User Manual

46
34 A3-J4-15 Area 8 Gnd In 18 AWG, Black Part of Valve Assembly
35 A3-J4-16 Area 8 Power In 18 AWG, Black Part of Valve Assembly
36 A3-J4-17 Ref Air Gnd In 18 AWG, Black Part of Valve Assembly
37 A3-J4-18 Ref Air Power In 18 AWG, Black Part of Valve Assembly
38 K1-14 A1-P4-1 24 AWG, White Low Relay Control
39 K1-13
A1-P4-2 24 AWG, Red
Low Relay Power
40 K2-14
A1-P4-3 24 AWG, White
Main Relay Control
41 K2-13
A1-P4-4 24 AWG, Red
Main Relay Power
42 K3-14
A1-P4-5 24 AWG, White
High Relay Control
43 K3-13
A1-P4-6 24 AWG, Red
High Relay Power
44 K4-14
A1-P4-7 24 AWG, White
Horn Relay Control
45 K4-14
A1-P4-8 24 AWG, Red
Horn Relay Power
46 K1-5 TB2-1 22 AWG, Black Customer Power to Low Relay
47 K1-9 TB2-2 22 AWG, White Switched Power from Low Relay
48 K2-5 TB2-3 22 AWG, Black Customer Power to Main Relay
49 K2-9 TB2-4 22 AWG, White Switched Power from Main Relay
50 K3-5 TB2-5 22 AWG, Black Customer Power to High Relay
51 K3-9 TB2-6 22 AWG, White Switched Power from High Relay
52 K4-5 TB2-7 22 AWG, Black Customer Power to Horn Relay
53 K4-9 TB2-8 22 AWG, White Switched Power from Horn Relay
54 TB3-1 A1-P8-1
24 AWG, White
Analog 1 Out
55 TB3-2 A1-P8-3
24 AWG, White
Analog 2 Out
56 TB3-3 A1-P8-2
24 AWG, Black
Ref Gnd
57 TB3-4 A1-P3-2
24 AWG, White
External Reset In
58 TB3-5 A1-P8-4
24 AWG, Black
Ref Gnd
59 TB3-6 A1-P6-1
24 AWG, Blue
RS485 tx
60 TB3-7 A1-P6-1
24 AWG, Black
Ref Gnd (Shield Gnd)
61 TB3-8 A1-P6-1
24 AWG, White
RS485 rx
62 TB4-2 A1-P5-2
24 AWG, Red
24 VDC Loop Power (optional)
63 TB4-3 A1-P3-4
24 AWG, White
Channel 2 Analog Input (optional)
64 TB4-4 A1-P3-5
24 AWG, White Channel 3 Analog Input (optional)
65 TB4-5 A1-P3-6
24 AWG, White Channel 4 Analog Input (optional)
66 TB4-6 A1-P3-7
24 AWG, White Channel 5 Analog Input (optional)
67 TB4-7 A1-P3-8
24 AWG, Black Ref Gnd
68 A1-P7-1 A2-DET-P1-1
24 AWG, Red Detector Power
69 A1-P7-2 A2-DET-P1-2
24 AWG, White
Detector Signal
70 A1-P7-4 A2-DET-P1-3
24 AWG, Black
Ref Gnd
71 A1-P7-3 SW1-COM
24 AWG, White
Switched Gnd (Flow)
72 A1-P7-4 SW1-NC
24 AWG, Black
Ref Gnd
73 A4-J2 A5-J2 Ribbon Part of Keypad Assembly
74 A3-J2 A5-J1 Ribbon Part of Keypad Assembly
