Sentry Sample Sentry II 37
Spare Parts List
ID Description Sentry P/N
BPR/RV Sentry Backpressure Regulator/Relief Valve (20 PSI)
Replacement Diaphragm Kit
7-00868A
6-04084A
FE/FT-1 Flow Sensor with Fittings 6-04953D
M Motor
VREL – Motor Coupling Kit
Needle Valve – Motor Coupling Kit
Call Factory
6-05642C
7-04767B*
PT-1 Pressure Transducer (0-3000 PSI)
Cable, 3 wire Packard connection
4-05060F
4-05060G
SC-1, SC-2 Sample Cooler, TLR-4225
Gasket for TLF-4225
Gasket for TLR-4225
Sample Cooler, FLR-6225
Gasket for FLF-6225
Gasket for FLR-6225
7-03951A
2-03800B
2-03800F
7-03953A
2-03800A
2-03800E
SV-1 Solenoid Valve (Pilot Valve for Actuator) 4-05687A
SV-2 Solenoid Valve, Analyzer Shuto 4-05687B
TE-1, TE-2, TE-3 Temperature Elements 2-04281E
V-2 Sample Inlet Isolation/ Blowdown Valves
1/4" Compression Low Temperature/Low Pressure
Packing for above
1/4" Compression High Temperature/High Pressure
Packing for above
3/8" Compression Low Temperature/Low Pressure
Packing for above
3/8" Compression High Temperature/High Pressure
Packing for above
4-03599B
4-00348F
4-01856C
4-00348A
4-00473A
4-00348L
4-03247B
4-00348B
V-1 Sample Shuto Valve (Actuator and Valve) 4-01580Q
V-4 Cooling Water Inlet Valve (3-way), Bronze
Cooling Water Inlet Valve (3-way), Stainless
4-01139G
4-00920D
V-5 Cooling Water Outlet Valve (Globe), Bronze
Cooling Water Outlet Valve (Globe), Stainless
4-00787B
4-04855B
VREL Sentry High Pressure Control Valve
Seal Kit
Needle Valve – High Cv
7-00744A
6-02302C
4-01237A*
SG Cooling Water Sight Glass, Bronze
Cooling Water Sight Glass, Stainless
4-05729B
4-05729A
* If original unit was purchased before April 2014, consult factory for replacement needle valve parts.
