35
IRLED Luminance
Select the desired lightness for the IR LED.
Options
Enable Microphone
Enable audio by checking this checkbox. Using Audio will increase
the bandwidth requirements slightly.
Audio Type
Select the desired audio type.
Flip
This setting will have the image swapped top-to-bottom.
Mirror
This setting will have the image swapped left-to-right.
Enable Time Stamp
If enabled, the current time will be displayed on the Video image.
Enable Text
Display
Enable this setting if you want text to be displayed on the Video
image, and enter the desired text - up to 20 characters. This feature
is often used to identify each camera when multiple cameras are
installed.
